10.29 mm 13.72 mm 17.15 mm 21.34 mm 26.67 mm 33.4 mm 42.16 mm 48.26 mm 60.33 mm 73.03 mm 88.9 mm 101.6 mm 114.3 mm 141.3 mm 168.28 mm 219.06 mm 273.05 mm 323.85 mm 355.6 mm 406.4 mm 457.2 mm 508 mm 558.8 mm 609.6 mm 660.4 mm 711.2 mm 762 mm 812.8 mm

DN NPS ODANSI B36.19ANSI B36.10
mm 5s 10s 40s 80s 10 20 30 STD 40 60 XS 80 100 120 140 160 XXS
6 1/8" 10.29 1.24 1.73 2.41 1.73 1.73 2.41 2.41
8 1/4" 13.72 1.65 2.24 3.02 2.24 2.24 3.02 3.02
10 3/8" 17.15 1.65 2.31 3.20 2.31 2.31 3.20 3.20
15 1/2" 21.34 1.65 2.11 2.77 3.73 2.77 2.77 3.73 3.73 4.78 7.47
20 3/4" 26.67 1.65 2.11 2.87 3.91 2.87 2.87 3.91 3.91 5.56 7.82
25 1" 33.4 1.65 2.77 3.38 4.55 3.38 3.38 4.55 4.55 6.35 9.09
32 1 1/4" 42.16 1.65 2.77 3.56 4.85 3.56 3.56 4.85 4.85 6.35 9.70
40 1 1/2" 48.26 1.65 2.77 3.68 5.08 3.68 3.68 5.08 5.08 7.14 10.16
50 2" 60.33 1.65 2.77 3.91 5.54 3.91 3.91 5.54 5.54 8.74 11.07
65 2 1/2" 73.03 2.11 3.05 5.16 7.01 5.16 5.16 7.01 7.01 9.52 14.02
80 3" 88.9 2.11 3.05 5.49 7.62 5.49 5.49 7.62 7.62 11.13 15.24
90 3 1/2" 101.6 2.11 3.05 5.74 8.08 5.74 5.74 8.08 8.08
100 4" 114.3 2.11 3.05 6.02 8.56 6.02 6.02 8.56 8.56 11.13 13.50 17.12
125 5" 141.3 2.77 3.40 6.55 9.52 6.55 6.55 9.52 9.52 12.70 15.90 19.50
150 6" 168.28 2.77 3.40 7.11 10.97 7.11 7.11 10.97 10.97 14.30 18.20 21.96
200 8" 219.06 2.77 3.76 8.18 12.70 6.35 7.04 8.18 8.18 10.30 12.70 12.70 15.10 18.20 20.60 23.00 22.22
250 10" 273.05 3.40 4.19 9.27 12.70 6.35 7.80 9.27 9.27 12.70 12.70 15.90 18.26 21.44 25.40 28.58
300 12" 323.85 3.96 4.57 9.52 12.70 6.35 8.38 9.52 10.31 14.27 12.70 17.48 21.44 25.40 28.58 33.32
350 14" 355.6 4.19 4.78 6.35 7.92 9.52 9.52 11.13 15.09 12.70 19.05 23.83 27.79 31.75 35.71
400 16" 406.4 4.19 4.78 6.35 7.92 9.52 9.52 12.70 16.66 12.70 21.44 26.19 30.96 36.53 40.49
450 18" 457.2 4.19 4.78 6.35 7.92 11.13 9.52 14.27 19.05 12.70 23.83 29.36 34.92 39.67 45.24
500 20" 508 4.77 5.53 6.35 9.52 12.70 9.52 15.09 20.62 12.70 26.19 32.54 38.10 44.45 50.01
550 22" 558.8 4.77 5.53 6.35 9.52 12.70 9.52 15.87 22.22 12.70 28.57 34.92 41.27 47.62 53.97
600 24" 609.6 5.54 6.35 6.35 9.52 14.70 9.52 17.48 24.61 12.70 30.96 38.89 46.02 52.37 59.54
650 26" 660.4 7.92 12.70 9.59 12.70
700 28" 711.2 7.92 12.70 15.88 9.59 12.70
750 30" 762 6.35 7.92 7.92 12.70 15.88 9.59 12.70
800 32" 812.8 7.92 12.70 15.88 9.59 12.70
